Neway VM702H
Technical specs
- X travel
- 650 mm
- Y travel
- 420 mm
- Z travel
- 500 mm
- Table width
- 420 mm
- Table length
- 750 mm
- Spindle power
- 5.5 kW
- Spindle speed
- 10000 rpm
- Tool magazine
- 20
- Spindle taper
- 40
- Dimensions
- 2020x2320x2700 mm
- Control unit
- FANUC 0i-MD
Values are for standard equipment; the machine in a company record may differ.
Description
Neway VM702H vertical machining center has 650 mm X, 420 mm Y and 500 mm Z axis travel. The table, 750 mm long and 420 mm wide, operates with 5.5 kW motor power and 10000 rpm spindle speed. It is equipped with a 20-tool capacity magazine and Fanuc 0i-MD control unit.
This description was compiled automatically from public manufacturer sources; it makes no price or lead-time promise. This text was translated automatically.
Control unit
1 recordThe control unit used on this machine.
machinaX.co Editor’s Note
The Neway VM702H is a vertical center for mid-size batch parts, with a 750 x 420 mm table and 10,000 rpm spindle. Its 5.5 kW motor sits at the lower end for this table size, so heavy cutting capacity is worth verifying. The Fanuc 0i-MD control and 40-taper spindle accept standard tooling.
This is the platform's statement, not information from the companies. This text was translated automatically.
